Mosconi One 90.8 DSP Technology

The MOSCONI ONE 90.8 DSP is a universal 8-channel high-quality amplifier using Class AB technology and an integrated digital sound processor. It is the ideal power amplifier for speaker systems and/or efficient subwoofers. The digital 8-channel sound processor allows you to perfectly configure your car audio system using PC software. In addition to a comprehensive active crossover, equalizer, and time alignment, various special filters are also available. For system expansion, the ONE 90.8 DSP features a processed preamplifier output. Here you can conveniently connect the "Line IN" of another mono or stereo amplifier.

• Automatic power-on (High Level, SE or BTL mode only)
• Switchable 6-channel / 8-channel mode
• AUX inputs
• Auto-fading between inputs
• Signal mixing capability
• USB cable for PC connection
• BT wireless module for PC connection (optional)
• GUI (Windows XP, Vista 32/64-bit and 7 32/64-bit)
• Presets: 4
• 30-band parametric equalizer
• Implemented filter type: all standard filters available
• High-pass frequency range for each channel: 10 to 20,000 Hz
• LP frequency range for each channel Hz 10 ÷ 20000
• Slope of the HP and LP filters for each cell dB/Oct 6 to 24 (up to 48 when cascaded)
• Bandpass allowed yes
• Variable "Q" 0.25 ÷ 40
• Time delay ms 0 ÷ 15 (0.02 steps)
• Phase reversal for each channel 0 / 180°
• Gain level for each channel dB -115.5 ÷ 6
• Remote volume control (optional)
• MOLEX connector for speaker outputs

TECHNICAL DATA MOSCONI 90.8 DSP

PERFORMANCE:

• Output power at 4 ohms: 8 x 90 watts
• Output power at 4 ohms: 4 x 85 watts + 2 x 250 watts BTL
• Output power at 2 ohms: 8 x 120 watts
• Bridge power at 4 ohms: 4 x 240 watts
• Input sensitivity: 0.8 V - 17 V (LL / HL)
• Weight: 2.6 kg
